Automatic perfume filling machine line perfume filling machinery smal

short description:

This Vacuum small perfume bottle filling and crimping machine is auto negative pressure vacuum filling, auto bottle detecting( no bottle no filling ), filling for three times. Auto dropping of crimp pump cap, circulation of spray bottles’ die set, It is wide adaptability which can meet to requirements of different dimension and filling volume of containers.
This filling machine can be divided into automatic bottles feeding (Also can use choose manual load bottle) automatic filling, automatic pump cap capping head, pre-capping head for regulate and tighten up pump cap head and automatic capping etc.

This is automatic perfume filling and capping machine video,our machine is customized according to your requirements

Send email to us

Product Detail

Product Tags

Product Display

Overview

This machine is auto negative pressure vacuum filling, auto bottle detecting( no bottle no filling )

Auto dropping of crimp pump cap, circulation of spray bottles’ die set, It is wide adaptability which can meet to requirements of different dimension and filling volume of containers.

This filling machine can be divided into automatic bottles feeding (Also can use choose manual load bottle)automatic filling, automatic pump cap capping head, pre-capping head for regulate and tighten up pump cap head and automatic capping etc.

Parameter

Product	Full Automatic Small Vial Bottle Filling Capping Labeling Machine
Output	1000-6000BPH, or customized
Filling Volume	10-100ml, or customized
Filling Material	Liquid, Gel or etc
Control	PLC and Touch Screen
Driving Motor	Servo Motor
Filling Type	Piston Pump, Peristaltic Pump
2.5Power	1.5KW
Machine Frame Material	SS304
Capping Head	Screwing, Pressing, Crimping Head ( According to the cap type)
Suitable Industry	Cosmetic, medical, food, detergent, etc

Machine configuration

Frame	SUS304 Stainless steel
Parts in contact with liquid	SUS316L Stainless steel
Electrical parts
Pneumatic part

Features

•Suitable for vial or small dose liquid filling, 2-30 ml. no drop, no bottle no fill.
• International branded configuration, steady machine structure make the whole machine work stable
• Can be connected to bottle unscrambler and labeling machine to work together.
• Adopts peristaltic pump or ceramic pump filling, more accurate, no drop.
• Emergency stop button and earth leakage protection circuit.

The Machine Details

Rotary table, No bottle no filling, No cap auto stop, easy for trouble shooting, No air machine alarm, Multiple parameters setting for different caps.

Filling system: lt can achieve automatic stopping when bottles are full, and automatic starting when bottles are lacked on the belt conveyor.

Filling head: Our filling head have 2 jackets You can see the filling split connect with 2 pipes.The outside jacket connect with vacuum suction air pipe.The inner jacket connect with filling perfume material pipe.

Capping station

Capping head all will customize according to customer different cap.

Adopt Cap Unscrambler, it's customized according to your caps and inner plugs

Shanghai Panda Intelligent Machinery Co., Ltd. is a comprehensive enterprise specialized in the design, manufacture, R&D, trade of filling equipment and packaging equipment.
